2-5ms
Latency
15m
Range
~46sec
Boot Time
58mm
Form Factor
How It Works

Three steps. Zero cables.

01

Mount

Mount it next to your aftermarket ECU or TCU. 58×58mm — smaller than a pack of cards. Plug in the USB cable, power from your ECU’s 5V output or a 12V-to-5V adapter.

02

Connect

Turn the key. Boots in under a minute, broadcasts its own WiFi network. Your laptop auto-connects, the Tracktuned Link app discovers your USB devices instantly.

03

Tune

Open NSP, PCLink, AEMTuner, MaxxTune, or any tuning software. Your ECU appears as a native virtual COM port. Maps, live data, firmware uploads, wideband logging, all work wirelessly.

Features

Built for the workshop.

Near-Zero Latency

2-5ms over WiFi using USB/IP protocol. Your tuning software can't tell the difference from a direct USB cable connection.

Serious Range

10-15m open air, 5-10m through walls and firewalls. Covers any dyno cell, rolling road, garage, or pit lane.

Quick Boot

Boots in under a minute. WiFi AP ready by the time you've opened your laptop.

Auto-Connect

Set once, forget forever. The app remembers your devices and reconnects automatically.

Universal USB

FTDI, CP210x, CH340, all USB serial chipsets supported. If your standalone ECU or TCU talks USB, it works.

Built-In Web Panel

Change WiFi name, password, channel, and update firmware from your browser at 192.168.8.1.

CAN Addon

Your phone is a keypad.

Plug a USB-CAN adapter into your Tracktuned Link and your phone becomes a wireless CAN keypad for your ECU. Up to 15 programmable buttons, four modes, custom labels, live LED feedback. No physical keypad needed.

Haltech Elite 15 buttons ECUMaster EMU Black 12 buttons CANTCU / Blink Marine 12 buttons MaxxECU coming soon Turbolamik coming soon
Learn More
Compatibility

Works with your standalone ECU and TCU.

Haltech NSP Link ECU PCLink AEM AEMTuner Ecumaster EMU Black MaxxECU MaxxTune Turbolamik TunerPro Any USB Serial

Works with any ECU or TCU that connects over USB serial (FTDI, CP210x, CH340). Proprietary dongle-based tools (HP Tuners, EcuTek, etc.) are not supported.

Specifications

The details.

Size58 × 58 × 25 mm
Power5V Micro USB (~200mA / 1W)
Draw~200mA (1W)
WiFi2.4GHz 802.11n (300Mbps)
ProtocolUSB/IP over WiFi
Latency2-5ms typical
Range10-15m open air, 5-10m through walls
USB1 × USB-A host port
Boot Time~46 seconds
FirmwareTracktuned Custom (OpenWrt 25.x)
ProcessorMediaTek MT7628 (580MHz MIPS)
RAM128 MB DDR2
AppWindows (macOS & Linux planned)

Ready to tune wirelessly?

Bloody hell, why are you still using a cable?

Buy Now — £90
